Mono subwoofer amplifier — 1,200 watts RMS x 1

A JL Audio HD Series amplifier offers steady performance from an ultra-compact chassis. The HD1200/1 mono amplifier pushes up to 1,200 watts RMS to your sub, from a 2" tall chassis that's about the size of a sheet of computer paper. The regulated power supply allows this amp to deliver its rated power to a wide range of impedances (from 1.5 to 4 ohms), even when voltage levels drop during heavy use.

PRODUCT DETAILS:

• mono subwoofer amplifier
• 1,200 watts RMS x 1 (rated power from 1.5 to 4 ohms)
• variable high- and low-pass filter (50-500 Hz 12 or 24dB/octave)
• switchable subsonic filter (30 Hz) and output polarity control
• removable power and speaker plugs
• Single Cycle Control Class D amplifier design
• Regulated, Intelligent Power Supply System (RIPS) ensures consistent power output over a wide range of battery voltages and load impedances
• differential-balanced inputs eliminate noise from your vehicle's electrical system
• preamp outputs
• 4-gauge power and ground leads and a 100-amp fuse recommended — wiring and hardware not included with amplifier
• no onboard fuses — when installing multiple amps in a system, an additional 100-amp in-line fuse between the distribution block and the amplifier is recommended
• 10-13/16"W x 2"H x 8-13/16"D
• Monoblock Class-D amplifier
• Self-adhesive JL Audio badge
• Power connector plug
• Speaker connector plug
• 4 Mounting feet
• 4 Bolts for mounting feet (M4 x 40mm)
• 4mm Allen wrench
• 2.5mm Allen wrench
• Owner's Manual
• Power wire note
